P0171 2010 TOYOTA CAMRY - Air/Fuel Mixture System Lean Bank 1
P0171 2010 TOYOTA CAMRY Possible Causes
- Intake air leaks
- Faulty front heated oxygen sensor
- Ignition misfiring
- Faulty fuel injectors
- Exhaust gas leaks
- Incorrect fuel pressure
- Lack of fuel
- Faulty Mass Air Flow (MAF) sensor
- Incorrect Positive Crankcase Ventilation (PCV) hose connection
How is the P0171 2010 TOYOTA CAMRY code repair?Start by checking the "Possible Causes" listed above. Visually inspect the related wiring harness and connectors. Check for damaged components and look for broken, bent, pushed out, or corroded connector's pins.
What is the cost to diagnose the P0171 2010 TOYOTA CAMRY code
Labor: 1.0The cost to diagnose the P0171 2010 TOYOTA CAMRY code is 1.0 hour of labor. The auto repair's diagnosis time and labor rates vary by location, vehicle's make and model, and even your engine type. Most auto repair shops charge between $75 and $150 per hour.
How much do you know about cars?
Take the AutoCodes.com automotive tests and turbo-charge your car repair knowledge
When is the code detected?- Fuel injection system does not operate properly.
- The amount of mixture ratio compensation is too small. (The mixture ratio is too lean.)
- Engine Light ON (or Service Engine Soon Warning Light)
- Excessive Fuel Consumption
P0171 2010 TOYOTA CAMRY MeaningThe fuel trim is related to the feedback compensation value, not to the basic injection time. The fuel trim consists of both the short-term and the long-term fuel trims. The short-term fuel trim is fuel compensation that is used to constantly maintain the air-fuel ratio at stoichiometric levels. The signal from the Air-Fuel Ratio (A/F) sensor indicates whether the air-fuel ratio is rich or lean compared to the stoichiometric ratio. This triggers a reduction in the fuel injection volume if the air-fuel ratio is rich and an increase in the fuel injection volume if it is lean.Factors such as individual engine differences, wear over time and changes in operating environment cause short-term fuel trim to vary from the central value. The long-term fuel trim, which controls overall fuel compensation, compensates for long-term deviations in the fuel trim from the central value caused by the short-term fuel trim compensation. If both the short-term and long-term fuel trims are lean or rich beyond predetermined values, it is interpreted as a malfunction, and the ECM illuminates the MIL and sets a DTC.
